Lesson 7 of 7 · about 15 minutes
Common Progressions, Transposing and the Capo
You'll be able to
- Play I-IV-V, I-V-vi-IV, I-vi-IV-V and the 12-bar blues in several keys
- Transpose a song to a new key using numbers or half-step counting
- Use a capo chart to play in any key with familiar open shapes
- Pick a key that fits a singer's range
Most songs you will write sit on one of four chord skeletons. Knowing them by number lets you write faster, hear changes on first listen, and steal shapes from the whole history of the music without stealing a single song. Then a capo lets you play any of them in whatever key the singer needs.
The four skeletons
Every chord below comes from the key tables in lesson 4. I checked each row against the scale it belongs to.
I - IV - V: the three-chord song
The base of old-time, honky-tonk, bluegrass, early rock and roll and a mountain of protest songs. Common orders are 1 4 1 5, 1 1 4 1 / 1 1 5 5, and 1 4 5 1.
| Key | I | IV | V |
|---|---|---|---|
| G | G | C | D |
| C | C | F | G |
| D | D | G | A |
| A | A | D | E |
| E | E | A | B |
I - V - vi - IV: the radio loop
Four chords, one bar each, around and around. It powers a huge share of pop and modern country choruses. It can sound stale if you lean on it, so let the melody do something surprising over it.
| Key | I | V | vi | IV |
|---|---|---|---|---|
| G | G | D | Em | C |
| C | C | G | Am | F |
| D | D | A | Bm | G |
| A | A | E | F#m | D |
| E | E | B | C#m | A |
I - vi - IV - V: the doo-wop turn
The 1950s ballad loop, still common in country love songs and slow gospel. Starting the vi chord early in a verse adds a sad tinge that the IV and V lift back out of.
| Key | I | vi | IV | V |
|---|---|---|---|---|
| G | G | Em | C | D |
| C | C | Am | F | G |
| D | D | Bm | G | A |
| A | A | F#m | D | E |
| E | E | C#m | A | B |
The 12-bar blues
Twelve bars, three chords, usually all played as dominant sevenths. Blues, Western swing, rockabilly and plenty of outlaw country sit on this frame. One chord per bar:
| I7 | I7 | I7 | I7 |
| IV7 | IV7 | I7 | I7 |
| V7 | IV7 | I7 | V7 |
| Key | I7 | IV7 | V7 |
|---|---|---|---|
| E | E7 (E G# B D) | A7 (A C# E G) | B7 (B D# F# A) |
| A | A7 (A C# E G) | D7 (D F# A C) | E7 (E G# B D) |
| G | G7 (G B D F) | C7 (C E G Bb) | D7 (D F# A C) |
| C | C7 (C E G Bb) | F7 (F A C Eb) | G7 (G B D F) |
The last bar, the V7, is the turnaround: it kicks you back to the top. On the final pass, end on I7 instead. A common variation, the "quick change," moves bar 2 to IV7 and back to I7 in bar 3.
Example: a gospel move
Gospel and old country hymns love turning the I chord into a I7 right before the IV. In G: G, G7, C, G. The F in G7 slides down a half step to the E in C, which pulls the ear forward. Then the "amen" ending: C to G, IV to I. Try it as 1 17 4 1 / 1 5 1 1 in any key. In D that is D, D7, G, D / D, A, D, D.
Transposing
To transpose is to move a song to a new key. You will do this every time a singer says "that's too high." Either of these methods works.
By numbers. Convert the chords to Nashville numbers in the old key, then read them back out in the new key. A song in G that goes G, Em, C, D is 1 6- 4 5. In A, 1 6- 4 5 is A, F#m, D, E. This is the safest method, because it keeps the spellings right.
By counting half steps. Move every chord the same number of half steps. G to A is up two half steps, so Em goes up two to F#m, C to D, D to E. Chord quality never changes: a minor stays minor, a 7 stays a 7.
Example: down a whole step
A singer finds a song in G a little high. Drop it two half steps to F.
| Number | 1 | 4 | 5 | 6- |
|---|---|---|---|---|
| In G | G | C | D | Em |
| In F | F | Bb | C | Dm |
F and Bb are barre chords on guitar, which most beginners hate. That is where the capo comes in.
The capo
A capo clamps across all six strings at one fret. It acts like a movable nut: every open string goes up one half step per fret. Your chord shapes stay the same, but everything sounds higher. Play a G shape with the capo on fret 2 and the guitar sounds an A chord.
Back to the singer who wanted F. Use D-shape chords with a capo on fret 3. D, G, A and Bm shapes sound as F, Bb, C and Dm, exactly the chart in the example. Or use E shapes at fret 1 (E, A, B, C#m shapes sound F, Bb, C, Dm), though B and C#m shapes are barre chords too, so the D-shape option is friendlier.
Capo chart: what key you are in
Find the shape you are playing on the left and the capo fret along the top. I computed each cell by counting half steps up from the shape and checked it against the low E string fret ladder in lesson 1.
| Shape | Fret 1 | Fret 2 | Fret 3 | Fret 4 | Fret 5 | Fret 6 | Fret 7 |
|---|---|---|---|---|---|---|---|
| C | C#/Db | D | Eb | E | F | F#/Gb | G |
| A | Bb | B | C | C#/Db | D | Eb | E |
| G | Ab | A | Bb | B | C | C#/Db | D |
| E | F | F#/Gb | G | Ab | A | Bb | B |
| D | Eb | E | F | F#/Gb | G | Ab | A |
Reverse chart: I need this key
| Key you need | Options |
|---|---|
| F | Capo 1, E shapes. Capo 3, D shapes. Capo 5, C shapes. |
| Bb | Capo 1, A shapes. Capo 3, G shapes. Capo 6, E shapes. |
| Eb | Capo 1, D shapes. Capo 3, C shapes. Capo 6, A shapes. |
| Ab | Capo 1, G shapes. Capo 4, E shapes. Capo 6, D shapes. |
| B | Capo 2, A shapes. Capo 4, G shapes. Capo 7, E shapes. |
| F# | Capo 2, E shapes. Capo 4, D shapes. Capo 6, C shapes. |
Capo habits that save grief: put the capo just behind the fret wire, not on top of it or in the middle of the space, or the strings buzz and go sharp. Check tuning after you clamp it, because a capo can pull strings a little sharp. And on a number chart, write the real key at the top, plus the capo note for guitar: "Key Bb (gtr capo 3, G shapes)." The bass player and the piano player need the real key, not your shapes.
Picking the key
The right key is the one where the singer's highest and lowest melody notes both sound good. Sing the lowest note of the verse and the highest note of the chorus. If the top strains, drop the key. If the bottom turns to mumble, raise it. Change one half step at a time and the capo makes each test take ten seconds.
Try it
- Play I-V-vi-IV in G, then in D, then in A. Notice the song "feels" the same and only the height changes.
- Play a 12-bar blues in E with a boom-chick rhythm from lesson 6. End on E7 the last time through.
- Take a song you play in G. Write it as numbers, then transpose it to Eb on paper. Play it with a capo on fret 1 using D shapes (convert the numbers into D-key chords). Check the result against the reverse chart.
- Find your own range: open SoundStudio, record yourself singing your lowest comfortable note and your highest comfortable note, and read both on the pitch line in the Wave + Pitch view. Now sing the lowest and highest notes of a song in its current key and compare. If the top note is past your comfortable top, count how many half steps over it is, drop the key by that much, and use the capo chart to find your new shapes.
Checklist
- I can play I-IV-V, I-V-vi-IV and I-vi-IV-V in at least three keys.
- I know the 12-bar blues form by heart.
- I can transpose by numbers or by counting half steps.
- I can find a capo position for any key using the charts.
- I write the real key and the capo note on every chart.
Pictures, Numbers and Infographics
Every rule in this module rests on a few physical facts: twelve equal half steps to the octave, each one a fixed ratio above the last, all hung from an agreed pitch for A. The numbers below are those reference values, and the first diagram is the major scale recipe from lesson 2 laid out on the twelve half steps.
By the numbers
- 440 Hz: the standard frequency for A4, the A above middle C, adopted unanimously by an international conference in London in 1939 and reaffirmed by the International Organization for Standardization in 1975. HyperPhysics, Georgia State University
- 12: equal semitones (half steps) in one octave of equal temperament, the tuning used for pianos and fretted guitars. HyperPhysics
- About 6%: how much higher in frequency each note of the equal tempered scale is than the note below it. HyperPhysics
- 100 cents: the size of one equal tempered semitone, the unit musicians use to compare tunings. HyperPhysics
- 422.5 Hz: the A of Handel's tuning fork, as reported by acoustics author Thomas Rossing. Music from that era is now played about 70 cents sharper than it was written. HyperPhysics
- 415, 430 and 466 Hz: other A pitches still in use: 415 by some baroque groups, 430 as "classical pitch" and 466 as "Chorton pitch." HyperPhysics
- One major third: the only gap on a standard E A D G B E guitar that is not a fourth, between the G and B strings. That is why chord shapes change on the B string. HyperPhysics
Current: In the News
Audio and video
- "Using a Capo (Guitar Lesson BC-163) Guitar for beginners Stage 6", JustinGuitar (YouTube), August 12, 2009. Shows how a capo works and how to use it to move familiar shapes into a new key.
- "12 Bar Blues Progression - Blues Rhythm Guitar Lessons [BL-203]", JustinGuitar (YouTube), November 11, 2011. Plays through the 12-bar blues, one of the progressions this lesson covers.
External resources
- "Common Chord Progressions", musictheory.net. Interactive lesson on why some chord moves are common and how progressions lead home.
- "All About Capos", JustinGuitar. Covers capo placement and using a capo to fit a song to a singer's range.
- "Part 2: I analyzed the chords of 1300 popular songs for patterns. This is what I found.", Hooktheory, June 27, 2012. Data from 1,300 songs shows I-V-vi-IV as the most common four-chord progression.
Check yourself
1. What is I-V-vi-IV in the key of D?
In D, I is D, V is A, vi is B minor and IV is G.
2. You play G-shape chords with a capo on the 3rd fret. What key does it sound in?
Each fret raises the pitch a half step. G up three half steps is G#, A, Bb.
3. The singer needs a song in Eb. Which capo setup works?
D up one half step is Eb. Capo 3 with C shapes would also work, but capo 2 with C shapes gives D and capo 3 with E shapes gives G.
4. In a standard 12-bar blues in A, which chord is in bar 9?
The standard 12-bar form puts the V chord in bar 9. In A, that is E7.
5. A song in G is C, G, D, Em in one line. Moved down a whole step to F, that line becomes:
Each chord drops two half steps: C to Bb, G to F, D to C, Em to Dm. The minor stays minor.
6. Why do folk players use a capo instead of learning barre chords in every key?
A capo moves the whole open-chord sound up the neck, so you keep the shapes and drones you know while matching the singer's key.
Terms in this lesson
- Progression
- A series of chords in order, usually repeating through a verse or chorus.
- 12-bar blues
- A 12-bar chord pattern built on I, IV and V, the base of blues, early rock and roll and a lot of country.
- Transpose
- To move a whole song up or down to a new key, shifting every chord by the same amount.
- Capo
- A clamp across the guitar neck that raises every open string by the same number of half steps.
- Turnaround
- The last bar or two of a section that leads back to the start, usually on the V chord.
